Technical Specifications
| Voltage Level(V) | 220V | ||
| Capacity(A) | 15A | 30A | 50A |
| System Parameters | |||
| Operating Voltage | 220(-30%~+20%) | ||
| Operating Frequency | 50Hz (±10%) | ||
| Current Transformers | 50:5 ~ 30000:5 | ||
| Efficiency | >97.5% | ||
| Compensate for Harmonics | 2-17th Odd Harmonics | ||
| Operating Mode | Auto-start after power on; filtering priority, optional reative power compensation | ||
| Full Response Time | ≤10ms | ||
| Active Power Loss | ≤2.5% | ||
| Methods of Communication | RS485, Modbus | ||
| Mechanical Properties | |||
| Heat Dissipation | Intelligent air cooling | ||
| Noise | ≤60dB | ||
| Protection Features | There are more than 20 kinds of protection such as overvoltage, undervoltage, overheating, overcurrent, short circuit, etc | ||
| CT Installation Location | Load side | ||
| Module Dimensions | 238*87*240 / 238*87*300 | ||
| Color | Black | ||
| Environmental Requirements | |||
| Operating Temperature | -25℃ ~ +55℃ | ||
| Elevation | <2000 meters (More than 1000 meters, for every 100 meters of additional elevation, the power is reduced by 1%.) | ||
| Relative Humidity | <90%, No condensation | ||
| Environmental Conditions | Installation site must have clean air, free of explosive and flammable hazards; no gases that damage insulation or corrode metals, no conductive dust, no rain, snow, or severe mold. | ||
